Advantages of Prismatic Sodium Battery Cell
I. Why Chose Prismatic Sodium Ion Cell in Year 2026
NFPP Sodium-ion Battery is the best solution for Energy Storage,In 2026, Highstar Sodium Battery Company Limited clearly follow the NFPP sodium battery technology route for energy storage, because of long cycle life, high safety, and wide temperature range performance to precisely match energy storage needs. There are 6 reasons to consider and select NFPP Prismatic Sodium Ion Cell
- Based on anode material, NFPP Sodium Ion Battery is safest.
Because of stable NFPP anode material structure, The mass-produced and needle-punched smokeless cells have fully passed rigorous safety testing, no risk of fire or explosion, significantly superior safety compared to lithium batteries, while LFP battery can not pass the nailing testing, it is easy to thermal runaway.
- More than 15000 cycles of NFPP sodium ion battery, Ultra-Long Service Life
There are more than 15000 cycles of NFPP sodium-ion battery, which can ensure more than 25 years service life. It is great ideal for house energy, industrial and commercial energy storage with long-term stability and low operating cost. While there are only 6000 cycles of LFP battery, its service life and lifespan is shorter than NFPP sodium ion battery
- NFPP sodium ion battery can operate at -40℃~80℃
NFPP sodium ion battery can charge and discharge in extreme hot summer, which not affect its usable capacity, charging and discharging efficiency. while it can discharge more than 85% capacity at -40℃, therefore it is very suitable for cold harsh environments. No need water-cooling or heating plate to help work.
- Charge and Discharge efficiency of NFPP sodium ion battery is more than 96%.
NFPP sodium ion battery cell support fast charging with extremely high safety requirement, such as the NFPP sodium ion battery can be charged from 20% to 80% in 30 minutes or even less minutes, Reduce energy loss and waste, and ensures safe operation for house,industrial and commercial energy storage system.
- Free of Lithium, Cobalt and Nickel, Eco-Friendly & Economical
There is no rare material,such as lithium,cobalt or nickel, NFPP sodium ion battery is green and sustainable, low cost of material and can meet environmental standards, green battery, green power.
- NFPP sodium ion battery cell certificated by UL, IEC and CE
Currently we have the certification of UL 1973 and UL9540A, IEC 62619 certificates and CE certificate from NFPP sodium ion cell to NFPP sodium ion battery Pack.
II. Technical Parameters of prismatic NFPP sodium ion cell
| Model | NaCP71173208-160E3 | |
| Type | Prismatic | |
| Cell Chemistry | NFPP | |
| Nominal Capacity | 160AH | |
| Nominal Energy | 450WH | |
| Initial IR | ≤0.30mΩ | |
| Nominal Voltage | 2.86V | |
| Weight | 4.65 ±0.3kg | |
| Charging Cut-off Voltage | 3.45V | |
| Discharging Cut-off Voltage | 1.5V | |
| Standard Charging Power | 225W | |
| Standard Discharging Power | 225W | |
| Nominal Cycles | ≥15000 | |
| Operation Temperature | Charging Temperature | 0~60℃ |
| Discharging Temperature | -40℃~60℃ | |
| Storage Temperature | -20℃~45℃ | |
| Dimensions(L*W*H) | 173.7×71.7x207mm | |
| Compliance | CE, RoHS,REACH,Cobalt free | |
| Certificates | MSDS, UN,IEC62619, UL 1973, UL9540A | |
